Optical

Wavelength

1310 ± 20 nm

Output   power range

2   ~ 30 mW (3 ~ 15dBm)

Optical   return loss

> 45 dB

RF

Bandwidth

47 ~ 862 MHz

RF   input level

70   ~ 90 dBuV (recommend 80 dBuV)

Flatness,   peak-to-valley

± 0.75 dB

Impedance

75   Ω

Input   return loss

≥ 16 (47 ~ 550)MHz; ≥ 14   (550 ~ 750/862)MHz

CNR

≥   51 dB

CTB

≥ 65 dB

CSO

≥   60 dB

AGC\MGC   range

± 8 dB

User interface

Optical   connector

FC/APC or SC/APC

RF   connector

F-“Female”   connector

Power   supply

AC220V ( 100 ~ 240V) or   DC48V (35 ~ 72V)

HMI

LCD   display, 4*button, 5*LED

Online   monitor

Ethernet

Other characteristic

Machine   power consumption

Max 10 W

Operating   temperature

-10ºC   to + 50ºC

Storage   temperature

-20ºC   to + 65ºC

Relative   humidity

10%   to 95%  (no condensing)

Dimension

423 × 330 × 45 mm   (package 575 × 488 × 89 mm)

Weight

6Kg
