GPON 8 Port OLT SFP Slot HY-15-OLT8PG


Description

HY-15-OLT4/8/16PG series GPON OLT products are 1U height 19 inch rack mount products. The features of the OLT are small, convenient, flexible, easy to deploy, high performance. It is appropriate to be deployed in compact room environment. The OLTs can be used for “Triple-Play”,VPN, IP Camera, Enterprise LAN and ICT applications

HY-15-OLT8PG provides 8GE(copper) and 8SFP(6*1GE+2*10GE) slots independent interface for uplink, and 8*GPON OLT ports for downstream. It can support 1024 ONUs under 1:128 splitter ratio GH OLT Series OLT interface





Specification

Products

HY-15-OLT4PG

HY-15-OLT8PG

HY-15-OLT16PG

Chassic

Racks

1U 19 inch standard box

1U 19 inch standard box

1U 19 inch standard box

1G/10G Uplink Port

QTY

6

16

12

Copper

4*10/100/1000M auto-negotiation

8*10/100/1000M auto-negotiation

8*10/100/1000M auto-negotiation

SFP(Independent)

2*SFP+ (SFP+ is compatible with 10GE)

6*SFP and 2*SFP+ (SFP+ is compatible with 10GE)

4*SFP+ (SFP+ is compatible with 10GE)

GPON Port

QTY

4

8

16

Physical Interface

SFP Slots

SFP Slots

SFP Slots

Management Ports

1*10/100BASE-T out-band port(AUX), 1*CONSOLE port

Management Mode

SNMP, WEB, Telnet and CLI


Item

HY-15-OLT4PG

HY-15-OLT8PG

HY-15-OLT16PG

Chassis

Rack

1U 19 inch standard box

1U 19 inch standard box

1U 19 inch standard box

1000M

Uplink Port

QTY

4

8

8

Copper

10/100/1000M auto-negotiation

4

8

8

SFP

1000M,Duplex

(independent)

2

4

4

SFP+

SFP+ is 10GE

(independent)

2

2

4

GPON Port

QTY

4

8

16

Physical Interface

SFP Slot

Connector Type

Class B+/C+/C++



Max splitting ratio

1:128

Management Ports

1*10/100BASE-T out-band port, 1*CONSOLE port

PON Port Specification

Transmission Distance

20KM

20KM

20KM

GPON port speed

Upstream 1.244G, Downstream 2.488G

Wavelength

TX 1490nm, RX 1310nm

Connector

SC/PC

Fiber Type

9/125 um SMF

TX Power

+1~+5dBm

Rx Sensitivity

-28dBm

Saturation Optical Power

-8dBm

Management Mode

SNMP, Telnet ,CLI,WEB

Management Function

Fan Group Detecting;

Port Status monitoring and configuration management;

Layer2 switch configuration such as VLAN, Trunk,RSTP,IGMP,QOS, etc;

GPON management function: DBA,ONU authorization, ACL,QOS,etc;

Online ONU configuration and management;

User

Alam management

Layer2 Switch

16K Mac address

Support 4096 VLANs;

Support port VLAN and protocol VLAN;

Support VLAN tag/Un-tag ,VLAN transparent transmission;

Support VLAN translation and QinQ;

Support storm control based on port

Support port isolation

Support port rate limitation

Support 802.1D and 802.1W;

Support static LACP;

QOS based on port,VID,TOS and MAC address;

Access control list;

IEEE802.x flow control;

Port stability statistic and monitoring.

Multicast

IGMP snooping

256 IP Multicast Groups;

DHCP

DHCP server

DHCP relay

DHCP snooping

Layer 3 Route

Arp proxy

Static route

1024 hardware Host Routes;

512 hardware Subnet Routes;

GPON Function

Tcont dba;

Gemport traffic

In compliant with ITUT984.xstandard;

Up to 20KM transmission Distance;

Support data encryption, multi-cast, port VLAN, separation,RSTP,etc;

Support ONU auto-discovery/link detection/remote upgrade of software;

Support VLAN division and user separation to avoid broadcast storm;

Support power-off alarm function,easy for link problem detection;

Support broadcasting storm resistance function;

Support port isolation between different ports;

Support ACL and SNMP to configure data packet filter flexibly;

Specialized design for system breakdown prevention to maintain stable system;

Support RSTP,IGMP Proxy.

Tcont dba;

Gemport traffic

In compliant with ITUT984.xstandard;

Up to 20KM transmission Distance;

Support data encryption, multi-cast, port VLAN,

Dimension(L*W*H)

400mm*200mm*43.6mm

442mm*200mm*43.6mm

Weight

3.0kg

3.1kg

3.5kg

Power Supply

220VAC

AC:90~264V, 47/63Hz

Double Power Module

Hot Backup

Power Consumption

25W

Operating Environment

Working Temperature

-10~+55

Storage Temperature

40~+85

Relative Humidity

5~90%(non-conditioning)
