Optical

Wavelength

1550 ± 20 nm

Output power range

3 ~ 10 dBm

Optical return loss

> 45   dB

RF

Bandwidth

47 ~ 1002   MHz

RF input level

80±5  dBuV

Flatness, peak-to-valley

± 0.75   dB

Impedance

75 Ω

Input return loss

≥ 16

CNR

≥ 52 dB

CTB

≥ 63 dB

CSO

≥ 60 dB

AGC\MGC ATT range

0~20 dB

User   interface

Optical connector

FC/APC   or SC/APC

RF connector

F-“Female” connector

Power supply

DC 12V

HMI

OLCD   display, AGC button, 2*LED

Other   characteristic

Machine power consumption

<2 W

Operating temperature

-10ºC to + 50ºC

Storage temperature

-20ºC to + 65ºC

Relative humidity

10% to 95%    (no condensing)

Dimension

168   × 132 × 28 mm

Weight

300g
